ADF
SM 4-115 D062/D063/D065/D066
Replacement
and
Adjustment
4.13 ADF
4.13.1 ADF COVERS
1. Feed cover [A] (
x 2, all s, ground wire x 1).
2. Front cover [B] (
x 2)
Press down on the tabs to remove.
3. Rear cover [C] (
x 2)
Press down on the tabs to remove.
