Replacement and Adjustment
D454 18 SM
4. FM6 pawl motor [A] (
x 2)
1.3.5 2ND FOLD MOTOR
1. Rear upper cover ( p.4)
2. Rear lower cover ( p.4)
3. 2nd fold motor bracket [A] (
x 1, x 1, x 3)
4. 2nd fold motor [A] ( x 2)
