Test Pattern Printing
SM 5-9 D062/D063/D065/D066
System
Maintenance
5.3 TEST PATTERN PRINTING
5.3.1 PRINTING TEST PATTERN: SP2902-003
Some of these test patterns are used for copy image adjustments but most are used
primarily for design testing. These test patterns do not use the IPU.
Do not operate the machine until the test pattern is printed out completely.
Otherwise, an SC may occur.
1. Enter the SP mode and select SP2902-003.
2. Enter the number for the test pattern that you want to print and press . (See the
table below.)
3. When you are prompted to confirm your selection, press Yes to select the test pattern
for printing.
4. Press Copy Window to open the copy window, then select the settings for the test print
(paper size, etc.)
5. Press Start
twice (ignore the “Place Original” messages) to start the test print.
6. After checking the test pattern, press SP Mode (highlighted) to return to the SP mode
display.
7. Exit the SP mode.
Test Pattern Table
These patterns can be selected for SP2902-003
No. Test Pattern
0 None
1 Alternating Dot Pattern (1-dot)
2 Alternating Dot Pattern (2-dot)
3 Alternating Dot Pattern (4-dot)
4 Alternating Dot Pattern (1024-dot)
5 Grid Pattern (1-dot): 0ch
6 Grid Pattern (1-dot): 1ch
