PAPER END DETECTION
SM 15 B473
Large
Capacity Tray
B473
2.5 PAPER END DETECTION
The paper end sensor [A] monitors the light reflected by each sheet on top of the
stack.
When the last sheet feeds, the cutout [B] is exposed, and the paper end sensor
receives no reflected light from below because there is no paper and this signals
paper end.
B473D111.WMF
[A]
[B]
