Service Call Conditions
SM Appendix 3-19 D062/D063/D065/D066
Appendix:
Service Call
Conditions
ID sensor error 5
C
Vsg falls out of the adjustment target (4.0 ±0.2V) during Vsg checking.
354
-
ID sensor defective
ID sensor harness disconnected
ID sensor connector defective
IOB defective
ID sensor pattern not written correctly
Incorrect image density
Charge power pack defective
ID sensor dirty
ID sensor error 6
C
The Vp value, which measures the reflectivity of the ID sensor pattern, was
not in the range of -70V to -400V.
355
-
Potential sensor defective
Potential sensor harness defective
Potential sensor disconnected
IOB defective
OPC unit connector defective
Charge corona power pack defective
Charge corona wire dirty, broken
SC400: Image Development (2)
Transfer output abnormal
D
When the transfer is output, the feedback voltage remains higher than 4V
for 60 ms.
401
-
Transfer power pack defective
Transfer current terminal, transfer power pack disconnected, damaged
connector
