Paper Feed
D062/D063/D065/D066 4-102 SM
4.11.16 REGISTRATION SENSOR
1. Inner cover [A] (
x 4)
Remove:
Development unit (
p.4-43 "Removal ")
Charge corona unit (
p.4-28)
OPC drum unit (
p.4-30 "OPC Drum Removal")
2. Paper dust removal unit [B] (
x 1, x 1)
3. Registration sensor [C]
