Ricoh D065 - Installation; Tapes

Multi Folding Unit (D454)
D062/D063/D065/D066 2-36 SM
2.6.2 INSTALLATION
 The unit must be connected to a power source that is close to the unit and easily
accessible.
 Make sure that the main machine is switched off and that its power cord is
disconnected before doing the following procedure.
Tapes
1. Remove tape from front [A] and rear [B].
2. Open the front door [A].
3. Remove all tape from inside [B].
