PAPER SIZE ADJUSTMENT
B473 6 SM
1.7 PAPER SIZE ADJUSTMENT
The side fences [A] can be adjusted for A4 Sideways, B5 Sideways, or LT
sideways at the top [B] and bottom brackets [C].
After changing the side fences to accept another paper size, you must execute
SP5959 005 (Paper Type – Tray 4) and select the paper size of the side fence
positions. For details, see SP5959 in section “5. Service Tables” of the B064/B065
manual.
B473R109.WMF
[A]
[B]
[C]
