Copy Connector Kit (B328)
D062/D063/D065/D066 2-100 SM
Determine the number of cables and repeater hubs that are necessary based on the
distance measured between the machines.
Distance
Power Repeater Hubs
Required
Interface Cables Required
Up to 4.5 m (14.8 ft.) None 1
4.5 to 9.0 m (14.8 to 29.5 ft) 1 2
9.0 to 13.5 m (29.5 to 112.5 ft.) 2 3
Install the key labeled “Printer/Other Function + Scanner” (or its equivalent symbol
key-top for EU) on a machine with the printer/scanner option installed.
Install the key labeled “Other Function” (or its equivalent symbol key-top for EU) on a
machine without the printer/scanner option.
2.18.3 INSTALLATION
1. Remove these parts:
Rear upper cover (
x2) ( Replacement and Adjustment – Operation Panel
and External Covers)
Rear lower cover (
x2) ( Replacement and Adjustment – Operation Panel
and External Covers)
Controller box cover (
x 13)
Rev. 08/03/2009
To Next Page
