PM Tables
D062/D063/D065/D066 2-4 SM Appendix
300K 600K 1000K AN Exp. Note
Registration Sensor C Blower brush
Relay Sensor C Blower brush
Bypass Paper End
Sensor
C
Blower brush
Grip Rollers
C
Dry cloth, blower
brush
Vertical Guide Plate C Dry cloth
Paper Feed Guide Plate C Dry cloth
Vertical Transport Rollers C C Alcohol
Paper Feed Sensors C C Blower brush
Paper End Sensors C C Blower brush
Feed Rollers R 1000
Pick-up Rollers R 1000
Separation Rollers R 1000
See Notes below this
table.
Notes:
Always replace pick-up, feed and separation rollers as a set.
The target service life of the feed, pick-up, and separation rollers is 1000 K. However,
they should be replaced sooner if the machine begins to jam or double-feed.
Transfer Belt Unit
300K 450K 600K AN Exp. Note
Transfer Belt R 750
Transfer Roller Cleaning
Blade
R
750
Use dry cloth to clean
transfer belt. Always
replace transfer belt and
transfer roller cleaning
blade together.
