SPDF DF3080
D146/D147/D148/D149/D150 2-56 SM
2.10.2 INSTALLATION PROCEDURE
§ When you install this option, turn off the power supply to the machine, and unplug the
power plug from the wall socket.
§ If it is installed when the power is ON, it will result in an electric shock or a malfunction.
§ Do not turn the power on until you perform “adjustment after installation,” otherwise it
may not start normally.
Attaching the SPDF
1. Place the unit on the machine temporarily, and remove the orange tape and shipping
retainers.
2. Remove the items in the package (boards, fixing screws, etc.).
3. Attach the 2 stepped screws [A] to the machine.
To Next Page
