SD card for NetWare printing Type M4/M3

D146/D147/D148/D149/D150 2-182 SM

2.35 SD CARD FOR NETWARE PRINTING TYPE M4/M3

M4: D148/D149/D150, M3: D146/D147:

2.35.1 ACCESSORY CHECK

No. Description Q’ty

1 SD Card 1

2.35.2 INSTALLATION PROCEDURE

1. SD card slot covers [A] [B] ( ×1)

D148/D149/D150:

D146/D147:
