Booklet Finisher SR3150 / Finisher SR3140

D146/D147/D148/D149/D150 2-104 SM

2.17 BOOKLET FINISHER SR3150 / FINISHER SR3140

2.17.1 ACCESSORY CHECK

Booklet Finisher SR3150 / SR3140

No. Description Q’ty

1 Tray (SR3150 only) 1

2 Guide Plate 1

3 Ground Plate Joint Bracket 1

4 Front Bracket 1

5 Rear Bracket 1

6 Screws - M4 × 12 4

6 Tapping screws - M3 × 6 2

6 Tapping screw - M4 × 8 1

7 Shift Tray 1

8 Cushion 1

9 Arm Of The Anti-tip Component (SR3140 only) 1
