Feed Motor
SM 19 D779
ARDF DF3090
(D779)
1.15 FEED MOTOR
1. Rear cover ( page 1)
2. Feed motor harness [A] (
x 1)
3. Harness guide [A] (
x 5)
4. Feed motor with bracket [A] (
x 2, spring [B] x 1)
