System Maintenance Section 5-1 D146/D147/D148/D149/D150
Updating the
Firmware
5. UPDATING THE FIRMWARE
5.1 OVERVIEW
In order to update the firmware of this machine, it is necessary to download the latest version of
firmware on a SD card.
Insert the SD card in SD card slot 2 beside the left rear of the controller box.
Important firmware update information
• When updating machine firmware, make sure NOT to install Smart Panel supported
firmware on a machine with a normal operation panel (and vice-versa). If you do, the
machine may not function as designed and product warranty may not apply.
• To avoid this, when updating the firmware, make sure that the numbers next to “NEW” and
“ROM” are the same on the following screen:
• If the wrong firmware is installed, repeat the update procedure and check the numbers
mentioned above.
Overview, background
• For MFP’s that have the Smart Panel installed, all firmware installed on the machine from
that point onward should be Smart Panel supported firmware. Similarly, normal firmware
should only be installed on machines with the normal operation panel.
• Operationally, it is possible to install the wrong firmware (e.g. Smart Panel supported
firmware onto a machine with a normal operation panel). There are no alert messages or
protections to prevent this.
The names of the firmware appear on the firmware download site as follows:
For models with a Smart Panel:
MP C3005/3505 (Smart Operation Panel), MP C4503/5503/6003 (Smart Operation Panel)
For models with a normal operation panel:
MP C3005/3505, MP C4503/5503/6003
⇒
Rev. 10/7/2013
