Punch Unit PU3050
SM 2-111 D146/D147/D148/D149/D150
2.18 PUNCH UNIT PU3050
2.18.1 ACCESSORY CHECK
Description Q’ty
Harness 1
Hopper guide plate 1
Punch unit 1
Hopper 1
Stay 1
Guide plate 1
Registration Sensor unit 1
Stepping motor bracket 1
Tapping screws - M3 × 6 15
2.18.2 INSTALLATION PROCEDURE
§ When installing this option, turn the power source of the machine off, and unplug the
power plug from the wall socket.
§ If it is installed when the power is on, it will result in an electric shock or a malfunction.
