Output Check Table
System Maintenance Section 3-31 D146/D147/D148/D149/D150
Input and Output
Check
3.2 OUTPUT CHECK TABLE
5804 [OUTPUT Check]
001
Feed Pickup Solenoid 1 ENG [0 or 1 / 0 / 1/step]
Moves 1st paper feed tray pick up solenoid.
002
Feed Pickup Solenoid 2 ENG [0 or 1 / 0 / 1/step]
Moves 2nd paper feed tray pick up solenoid.
003
Bypass Pickup Solenoid ENG [0 or 1 / 0 / 1/step]
Moves bypass pick up solenoid.
004
Exit Junction Solenoid ENG [0 or 1 / 0 / 1/step]
Moves output paper divide solenoid.
5804
[OUTPUT Check]
Moves paper feed tray rising motor.
005 Tray 1 Lift Motor:CW ENG
[0 or 1 / 0 / 1/step]
006 Tray 1 Lift Motor:CCW ENG
007 Tray 2 Lift Motor:CW ENG
008 Tray 2 Lift Motor:CCW ENG
5804
[OUTPUT Check]
Moves register motor.
009
Regist Motor:CCW:Standard
Speed
ENG
[0 or 1 / 0 / 1/step]
010
Regist Motor:CCW:Middle
Speed
ENG
011
Regist Motor:CCW:Low
Speed
ENG
