Paper Sensor
SM 1 D692
1 BIN TRAY
BN3110 (D692)
1. REPLACEMENT AND ADJUSTMENT
1.1 PAPER SENSOR
1. Open the duplex unit.
2. Power supply cover [A]
3. Paper exit tray [A]
4. Upper left cover [A] ( ×1)
5. Left rear cover [A] ( ×2)
