Image Adjustment
D146/D147/D148/D149/D150 4-170 SM
Adjustment Procedure
1. Enter SP2-109-003.
2. Print out the test pattern (14: 1-dot trimming pattern) with SP2-109-003.
§ Registration can change slightly as shown on the previous page. Print some pages of
the 1-dot trimming pattern for step 3 and 4. Then average the leading edge and
side-to-side registration values, and adjust each SP mode.
3. Do the leading edge registration adjustment.
1) Check the leading edge registration and adjust it with SP1-001.
2) Select the adjustment conditions (paper type and process line speed).
3) Input the value. Then press the
key.
4) Generate a trim pattern to check the leading edge adjustment.
4. Do the side-to-side registration adjustment.
1) Check the side-to-side registration and adjust it with SP1-002.
2) Select the adjustment conditions (paper feed station).
3) Input the value. Then press the
key.
4) Generate a trim pattern to check the leading edge adjustment.
