Main SP Tables-1
D146/D147/D148/D149/D150 2-2 System Maintenance Section
2.2 MAIN SP TABLES-1
2.2.1 SP1-XXX (FEED)
1001
[Leading Edge Registration]
Adjust the image position against the transfer paper by adjusting timing of start
registration. Reflects adjustment values with no change.
“+” is the direction from which images come out. (Makes the registration start
fast.)
“-“ is the direction which images disappear. (Makes the registration start slow.)
001 Tray: Thin *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
002 Tray: Plain *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
003 Tray: Mid-thick *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
004 Tray: Thick 1 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
005 Tray: Thick 2 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
006 Tray: Thick 3 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
007 Tray: Thick 4 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
008 By-pass: Thin *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
009 By-pass: Plain *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
010 By-pass: Mid-thick *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
011 By-pass: Thick 1 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
012 By-pass: Thick 2 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
013 By-pass: Thick 3 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
014 By-pass: Thick 4 *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
015 Duplex: Thin *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
016 Duplex: Plain *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
017 Duplex: Mid-thick *ENG [-9.0 to 9.0 / 0.0 / 0.1mm/step]
To Next Page
