Electrical Component Defects

SM 5-215 D146/D147/D148/D149/D150

Troubleshooting

5.12.2 D146/D147

Name Output connector

Capacity Part number

Can be changed in

the field or not

Voltage Part name Remarks

FU101

CN985 (Fusing center

heater)

CN986 (Fusing edge heater)

15A 11071241 Yes

AC TLC-15A-N4

Installed on AC

control board

FU102 CN988 (DC power supply)

15A 11071241 Yes

AC TLC-15A-N4

Installed on AC

control board

FU3 CN912(IOB, SIO)

8A 11071283 Yes

24V

FBT 250V

8A(EM)

Installed on DC

power supply

FU4

CN917 (Interlock switch

[IOB])

8A 11071283 Yes

24V

FBT 250V

8A(EM)

Installed on DC

power supply

FU5

CN917 (Interlock switch

[IOB])

8A 11071283 Yes

24V

FBT 250V

8A(EM)

Installed on DC

power supply

FU7

CN913(FIN)

CN914(BANK)

8A 11071283 Yes

24V

FBT 250V

8A(EM)

Installed on DC

power supply
