Chapter 14 Snapshots
852
Snapshot Operations From the Numeric Keypad Control Block
3
Press the region selection button corresponding to the region for which you
want to save, turning it on. You can select more than one region.
[M/E 1], [M/E 2], [M/E 3], [M/E 4], [P/P]: These select the
corresponding M/E-1, M/E-2, M/E-3, M/E-4, and PGM/PST regions.
Notes
To select M/E 4, it is necessary to assign M/E 4 to a button.
For details of the assignment, see “Assigning a Region to the Region
Selection Buttons in the Numeric Keypad Control Block or Multifunction
Flexi Pad Control Block” in Chapter 19 (Volume 3).
[USER 1] to [USER 8]: These select the User regions.
[DME 1] to [DME 8]: These select the DME channels.
[RTR]: This selects the Router region.
[ALL]: This selects all regions.
Notes
The regions that can be selected simultaneously are those assigned to the
region selection buttons in the numeric keypad control block. (See
“Assigning a Region to a Region Selection Button in the Numeric Keypad
Control Block” in Chapter 19 (Volume 3).)
The first button pressed lights green as the reference region, and any
subsequently pressed buttons light amber.
Pressing one of the amber-lit buttons, while holding down [SNAPSHOT],
turns the button green to indicate its corresponding region as the new
reference region.
For details of the precedence order for becoming the reference region, see
“Reference region” (page 767).
The display shows the name of the reference region and the number of the
register previously recalled for that region.
4
Press the [STORE] button, turning it on.
5
Enter the desired register number from the numeric keypad.
To find an empty register, instead of entering a number, press the [.]
(period) button. To search for an empty register common to all currently
selectable regions, press the period button again.
