Chapter 14 Snapshots
863
Snapshot Operations in the Multifunction Flexi Pad Control Block
2
In the Multifunction Flexi Pad control block, press the [SNAPSHOT]
button.
This assigns the Multifunction Flexi Pad control block to snapshot
operations. The numeric display shows the last selected bank number and
the register number last recalled on the bank.
3
Press the region selection button corresponding to the region for which you
want to save, turning it on. You can select more than one region.
Notes
To select M/E 4, it is necessary to assign M/E 4 to a button.
For details of the assignment, see “Assigning a Region to the Region
Selection Buttons in the Numeric Keypad Control Block or Multifunction
Flexi Pad Control Block” in Chapter 19 (Volume 3).
[M/E 1], [M/E 2], [M/E 3], [M/E 4], [P/P]: These select the
corresponding M/E-1, M/E-2, M/E-3, M/E-4, and PGM/PST regions.
[USER 1] to [USER 8]: These select the User regions.
[DME 1] to [DME 8]: These select the DME channels.
[RTR]: This selects the Router region.
[ALL]: This selects all regions.
Notes
The regions that can be selected simultaneously are those assigned to the
region selection buttons in the memory recall section. (See “Assigning a
Region to a Region Selection Button in the Numeric Keypad Control Block
or Multifunction Flexi Pad Control Block” in Chapter 19 (Volume 3).)
The first pressed button lights green as the reference region, and any
subsequently pressed buttons light amber.
Pressing one of the amber-lit buttons, while holding down [SNAPSHOT],
turns the button green to indicate its corresponding region as the new
reference region.
For details of the precedence order for becoming the reference region, see
“Reference region” (page 767).
The display shows the name of the reference region and the number of the
register previously recalled for that region.
4
Press the [BANK SEL] button, and select the desired bank with the
numeric keypad buttons in the memory recall section.
To Next Page
