Zontes ZT310-T EURO IV User Manual

8、FUEL TANK COMPONENT 77
CHK
AD
J
NO. PART NO. PART NAME QTY CAUTION
1 1251100-102000
Non-standard bolt M6×16 (304 stainless steel)
6
2 1274100-057095
Flanging bushing φ6.2×φ8.4×3.5
＋
φ14×1.5 6
3 1244100-052000
Cuff bushing cushioning rubber (φ8.5×φ14×1) 6
4 1251300-063093
Splint M6×11×15 (environmental color) 8
ZT310-R fuel tank right decorative cover (dark gray /
decal blue / ADV)
4044201-151052
4044201-154052
7 1251500-081000
Non-standard flat mat φ13×φ8.2×1.5(environmental
color)
2
【1】
PROCEDURE:
●Left tank trim cover
First remove the bolt (1) at a, pull the bottom plate of the front cover of the front mud plate slightly, and remove
the bushing (2) and the cushion rubber (3). Then remove the other two bolts (1); remove the bushing (2) and the
cushion rubber (3).
Pull out in the order ①-②-③ and pull out the trim cover (5).
Press ④ with one hand and push the trim cover forward to remove the left trim cover (5).
Remove the splint (4) from the left trim cover (5).
●Right tank trim cover
Remove the right trim cover (6) by removing the left trim cover.
ZT310-R fuel tank left decorative cover (bright black /
decal titanium gold / ADV)
4044201-152052
ZT310-R fuel tank left decorative cover (dark gray /
decal blue / ADV)
Bright orange
vehicle
ZT310-R fuel tank right decorative cover (dark gray /
decal orange / ADV)
Special black
vehicle
Bright blue
vehicle
4044201-533052
ZT310-R fuel tank left decorative cover (dark gray /
decal white / ADV)
4044201-144021
ZT310-R fuel tank right decorative cover (bright black
/applique titanium gold / ADV)
Fig. 4 FUEL TANK
COMPONENT
5 1
6 1
4044201-534052
ZT310-R fuel tank right decorative cover (dark gray /
decal white / ADV)
4044201-155052
ZT310-R fuel tank left decorative cover (dark gray /
decal orange / ADV)
Special
black vehicle
Bright blue
vehicle
4044201-145021
Fuel tank cover component
Bright orange
vehicle
CAUTION:
●The left and right side covers and cushions must be removed in advance.
●The material should be protected during the disassembly process to prevent damage to the paint
surface. The trim cover is long and should be handled or held by both hands during disassembly or
assembly.
●When assembling, first fasten the④ buckles, then install the staples in the order of ③-②-①.
●【1】Increase non-standard flat mat⑺ at the bottonm mounting point of the left&right fuel tank
decorative cover from 16 Oct. 2019.
