10、REAR COVER COMPONENT 95
CHK
ADJ
NO. PART NO. PART NAME QTY CAUTION
1 1244100-072000
－
2 1184100-116000 ZT250 Lithium battery 1
3 1274200-078000
－
4 1184200-038044 ZT310 Lithium battery charger 1
Fig. 9 REAR COVE
COMPONENT
Battery component
PROCEDURE:
●Battery straps, vehicle tools
Pull the metal snap ring of the battery strap (1) in the direction of the arrow, press it down, remove it, and
remove the on-board tool (3).
●Battery
Unscrew the black protective cap ② to remove the negative pole；then remove the red protective cap ① and
remove the positive pole；remove the battery. For reinstallation, connect the positive electrode first, then
connect，the negative electrode. No parallel battery charging or ignition.Just use the battery charger''ZONTES''
provide for you
.PKE insurance must be removed before charging; the bracelet version cannot be unplugged. The
bracelet version of the PKE assembly integrates a charging interface, and some models may also have a charging
interface for the main harness.
CAUTION:
●Pull the plugs ①、② out of the cable.
●Reassemble the battery or fuse, etc. Be sure to reset the EFI hardware: Turn on the key-Ignition- 10 seconds
After the ignition is turned off - After 10 seconds Turn on the ignition switch and repeat 2 times.
●If the battery has reached the end of its useful life, it should be handed over to a qualified organization or a
dedicated recycling center for proper disposal. it is forbidden to discard it.
