20 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019

Chapter 1 Components of a Motion System

Help for Selecting Drives and

Motors

Motion Analyzer helps you select the appropriate Allen-Bradley® drives and

motors that are based on your load characteristics and typical motion

application cycles. The software guides you through wizard-like screens to

collect information specific to your application.

After you enter the information for your application, such as, load inertia,

gearbox ratio, feedback device, and brake requirements, the software generates

an easy-to-read list of recommended motors, drives, and other support

equipment.

You can access Motion Analyzer at

https://motionanalyzer.rockwellautomation.com
