98 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019

Chapter 4 Configure Integrated Motion Control Using Kinetix 5700 Drives

Configure the Master

Feedback

The Master Feedback category is available if the Feedback Configuration that

is specified in the General category is Master Feedback. The attributes that are

associated with the Master Feedback category are associated with Feedback 1.

Again, like the Load Feedback category, you must enter all information.
