D-Link DGS-1100-16/ME User Manual

DGS-1100/ME Metro Ethernet Managed Switch CLI Reference Guide
DGS-1100-24P/ME:admin#
config mld_snooping multicast_vlan_group
Purpose To specify that MLD snooping is to be configured for multicast vlan
groups on the Switch.
Syntax
config mld_snooping multicast_vlan_group <vlan_name 8>
[add | delete] ipv6_range <mcast_range 80>
Description
The config mld_snooping multicast_vlan_group command
specifies an MLD snooping multicast VLAN group on the Switch.
Parameters
<vlan_name 8> − The name of the VLAN for which MLD snooping is
to be configured. Up to 8 characters can be used.
[add | delete] − Specify whether to add or delete address ranges
defined in the following parameter <mcast_address_range>.
<mcast_range 80> − Specify the IPv6 address to be configured with
the MLD snooping multicast VLAN group.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the mld snooping multicast VLAN:
DGS-1100-24P/ME:admin#config mld_snooping multicast_vlan_group lala
add ipv6_range ffe1::99-ffe1::1:33
Command : config mld_snooping multicast_vlan_group lala add
ipv6_range ffe1::99-ffe1::1:33
Success.
DGS-1100-24P/ME:admin#
enable mld_snooping multicast_vlan
Purpose To enable MLD snooping multicast VLAN on the Switch.
Syntax
enable mld_snooping multicast_vlan
Description
The enable mld_snooping multicast_vlan command enables MLD
snooping multicast VLAN on the Switch.
MLD snooping and MLD snooping multicast VLAN will have different
behavior in the same packet. If both are enabled at the same time,
only MLD snooping will work.
Parameters None.
Restrictions Only administrator-level users can issue this command.
Example usage:
To enable MLD snooping multicast VLAN on the Switch:
DGS-1100-24P/ME:admin#enable mld_snooping multicast_vlan
Command : enable mld_snooping multicast_vlan
109
