D-Link DGS-1100-16/ME User Manual

DGS-1100/ME Metro Ethernet Managed Switch CLI Reference Guide
config voice_vlan oui
Purpose Configures the user-defined OUI of a Voice device(s) to be associated
with the Voice VLAN.
Syntax
config voice_vlan oui [add | delete] mac <mac_address> mask < addr_mask>
{description <desc 8> }
Description
To configure user-defined voice traffic OUIs. OUIs are used by the
switch to identify the voice traffic packets. There are a number of pre-
defined OUIs. The user can further define user-defined OUIs if needed.
A user-defined OUI cannot be the same as any of the pre-defined OUIs.
The following are the pre-defined voice traffic’s OUIs:
OUI
Vendor
Mnemonic name
00:E0:BB
3COM
3com
00:03:6B
Cisco
cisco
00:E0:75
Veritel
veritel
00:D0:1E
Pingtel
pingtel
00:01:E3
Siemens
siemens
00:60:B9
NEC/Philips
nec&philips
00:0F:E2
Huawei-3COM
huawei&3com
00:09:6E
Avaya
avaya
Parameters
add - Adds a user-defined OUI of a Voice device vendor.
delete - Deletes a user-defined OUI of a Voice device vendor.
mac <macaddr> - The user-defined OUI MAC address.
mask <maskaddr> - The user-defined OUI MAC address mask.
description<desc 8> - The text description for the user-defined OUI.
Restrictions Only administrator-level users can issue this command.
Example usage:
Adding a user-defined OUI of a Voice device:
DGS-1100-24P/ME:admin#
config voice_vlan oui add mac
e0:00:00:00:00:00 mask ff:ff:ff:ff:00:00 description TEST001
Command :
config voice_vlan oui add mac e0:00:00:00:00:00 mask
ff:ff:ff:ff:00:00 description TEST001
Success.
DGS-1100-24P/ME:admin#
config voice_vlan ports
Purpose Configures Voice VLAN aging time.
Syntax
config voice_vlan ports [ list <portlist> | all] [ state [enable |
disable] | mode [autotagged | autountagged | manual]]
Description This command is used to configure the Voice VLAN setting on the
Switch.
Parameters
list <portlist> - A range of ports to set.
154
