D-Link DGS-1100-16/ME User Manual

DGS-1100/ME Metro Ethernet Managed Switch CLI Reference Guide
Description
The create vlan command creates a VLAN on the Switch.
Parameters
name <vlan_name 8> − The name of the VLAN to be created. Each
VLAN name can be up to 8 characters.
tag <vlanid 2-4094> − The VLAN ID of the VLAN to be created. The
allowed values range from 2 to 4094.
vlanid <vidlist 2-4094> – The VLAN ID li
st of the VLAN to be
created.
Restrictions Only administrator-level users can issue this command.
Example usage:
To create a VLAN v1, tag 3:
DGS-1100-24P/ME:admin#create vlan name v1 tag 3
Command : create vlan name v1 tag 3
Success.
DGS-1100-24P/ME:admin#
delete vlan
Purpose To delete a previously configured VLAN on the Switch.
Syntax
delete vlan [name <vlan_name 8> | vlanid <vidlist 2-4094>]
Description
The delete vlan command deletes a previously configured VLAN on
the Switch.
Parameters
name <vlan_name 8> − The name of the VLAN to be deleted.
vlanid <vidlist 2-4092> − The VLAN of the VLAN to be deleted.
Restrictions Only administrator-level users can issue this command.
Example usage:
To remove a vlan which VLAN ID is 2:
DGS-1100-24P/ME:admin#delete vlan vlanid 2
Command : delete vlan vlanid 2
Success.
DGS-1100-24P/ME:admin#
config vlan
Purpose To add additional ports to a previously configured VLAN and to
modify a VLAN name.
Syntax
config vlan [name <vlan_name 8> [add [tagged | untagg
ed] |
delete ] <portlist> | vlanid <vidlist 1-4094>]
[[add [tagged |
untagged] | delete ] <portlist> | name <vlan_name 8>]]
79

D-Link DGS-1100-16/ME Specifications

General

Ports	16 x 10/100/1000BASE-T
Switching Capacity	32 Gbps
Forwarding Rate	23.8 Mpps
Layer	Layer 2
MAC Address Table	8K
Dimensions	440 x 180 x 44 mm
Switch Type	Managed
Humidity	5% to 95% non-condensing
Jumbo Frame Support	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Certifications	CE, FCC
