DGS-1100/ME Metro Ethernet Managed Switch CLI Reference Guide
eth20 No Limit No Limit
eth21 No Limit No Limit
eth22 No Limit No Limit
eth23 No Limit No Limit
eth24 No Limit No Limit
Total Entries: 24
DGS-1100-24P/ME:admin#
show 802.1p user_priority
Purpose To display the 802.1p user priority.
Syntax
show 802.1p user_priority
Description
The show 802.1p user_priority command is used to display the
802.1p user_priority on the Switch.
Parameters None.
Restrictions None.
Example usage:
To display the QoS mode on the Switch:
DGS-1100-24P/ME:admin#show 802.1p user_priority
Command : show 802.1p user_priority
Priority-0 -> < Class-1(Medium Queue) >
Priority-1 -> < Class-0(Low Queue) >
Priority-2 -> < Class-0(Low Queue) >
Priority-3 -> < Class-1(Medium Queue) >
Priority-4 -> < Class-2(High Queue) >
Priority-5 -> < Class-2(High Queue) >
Priority-6 -> < Class-3(Highest Queue) >
Priority-7 -> < Class-3(Highest Queue) >
DGS-1100-24P/ME:admin#
config scheduling_mechanism
Purpose To configure the scheduling mechanism for the QoS function.
Syntax
config scheduling_mechanism { ports <portlist> } [sp | wrr]
Description
The config scheduling_mechanism
command configures the
scheduling mechanism for the QoS function. It allows the user to
select between a round robin (WRR) and a strict mechanism for
emptying the priority classes of service of the QoS function. The
Switch contains four hardware priority classes of service. Incoming
packets must be mapped to one of these four hardware priority
classes of service, or queues. This command is used to specify the
rotation by which these four hardware priority queues are emptied.
71
