D-Link DGS-1100-16/ME User Manual

DGS-1100/ME Metro Ethernet Managed Switch CLI Reference Guide
30
VOICE VLAN COMMANDS
The voice vlan commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.
Command Parameter
enable voice_vlan
[ name <vlan_name 8> | vlanid <vlanid 1-4094>]
disable voice_vlan
config voice_vlan
priority
<0-7>
config voice_vlan
aging_time
<min 1-65535>
config voice_vlan oui
[add | delete] mac <macaddr> mask <macmask> { description <desc 8> }
config voice_vlan ports
config voice_vlan ports [ list <portlist> | all] [ state [enable | disable] | mode
[autotagged | autountagged | manual]]
show voice_vlan global
show voice_vlan oui
show voice_vlan
voice_device
{ports <portlist>}
show surveillance_vlan
ports
[list <portlist> | all]
Each command is listed in detail, as follows:
enable voice_vlan
Purpose Enables the global Voice VLAN function.
Syntax
enable voice_vlan [ name <vlan_name 8> | vlanid <vlanid 1-4094>]
Description To enable the Voice VLAN function on a switch, the Vo
ice VLAN
must be assigned a name and there must be an existing static
802.1Q VLAN.
To change the Voice VLAN parameters, the user must disable the
Voice VLAN function and then re-issue the enable command.
Parameters
name <vlan_name 8> - The name of the voice VLAN
vlanid <vlanid 1-4094> - The VLAN ID of the voice VLAN.
Restrictions Only administrator-level users can issue this command.
151
