group_id <value>
config link_aggregation group_id <value> ports <portlist>
show link_aggregation {group_id <value>}
Each command is listed in detail, as follows:
create link_aggregation
Purpose To create a link aggregation group on the Switch.
Syntax
create link_aggregation group_id <value> {type [lacp | static]}
Description
The create link_aggregation command creates a link aggregation
group with a unique identifier.
Parameters
group_id <value> − Specifies the group ID. The group number
identifies each of the groups.
type – Specify the type of link aggregation used for the group. If the
type is not specified, the default type is static.
• lacp – This designates the port group as LACP compliant. LACP
allows dynamic adjustment to the aggregated port group. LACP
compliant ports may be further configured (see config lacp_ports).
LACP compliant must be connected to LACP compliant devices. The
maximum amount ports that can be configured in the same LACP
are 8.
• static – This designates the aggregated port group as static.
Static port groups cannot be changed as easily as LACP compliant
port groups, since both linked devices must be manually configured
if the configuration of the trunked group is changed. If static link
aggregation is used, be sure that both ends of the connection are
properly configured and that all ports have the same speed/duplex
settings. The maximum ports that can be configure in the same
static LAG are 8
Restrictions Only administrator-level users can issue this command.
161
