Configuring the Switch
3-98
3
Web – Click Port, LACP, Port Counters Information. Select a member port to display
the corresponding information.
Figure 3-59. Displaying LACP Port Counters Information
CLI – The following example displays LACP counters for port channel 1.
Displaying LACP Settings and Status for the Local Side
You can display configuration settings and the operational state for the local side of
an link aggregation.
Internal Configuration Information
Console#show 1 lacp counters 4-170
Channel group : 1
-----------------------------------------------------------------------
Eth 1/ 1
-----------------------------------------------------------------------
LACPDUs Sent : 21
LACPDUs Received : 21
Marker Sent : 0
Marker Received : 0
LACPDUs Unknown Pkts : 0
LACPDUs Illegal Pkts : 0
.
.
.
Console#
Table 3-8. LACP Settings
Field Description
Oper Key Current operational value of the key for the aggregation port.
Admin Key Current administrative value of the key for the aggregation port.
LACPDUs Internal Number of seconds before invalidating received LACPDU information.
LACP System Priority LACP system priority assigned to this port channel.
