Link Aggregation Commands
4-173
4
Console#show lacp 1 neighbors
Channel group 1 neighbors
-------------------------------------------------------------------------
Eth 1/1
-------------------------------------------------------------------------
Partner Admin System ID : 32768, 00-00-00-00-00-00
Partner Oper System ID : 32768, 00-00-00-00-00-01
Partner Admin Port Number : 1
Partner Oper Port Number : 1
Port Admin Priority : 32768
Port Oper Priority : 32768
Admin Key : 0
Oper Key : 4
Admin State : defaulted, distributing, collecting, synchronization,
long timeout,
Oper State : distributing, collecting, synchronization, aggregation,
long timeout, LACP-activity
.
.
.
Table 4-55. Show LACP Neighbors Output Contents
Field Description
Partner Admin System ID LAG partner’s system ID assigned by the user.
Partner Oper System ID LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port
Number
Current administrative value of the port number for the protocol Partner.
Partner Oper
Port
Number
Operational port number assigned to this aggregation port by the port’s protocol
partner.
Port Admin Priority Current administrative value of the port priority for the protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding table.)
Oper State Operational values of the partner’s state parameters. (See preceding table.)
Console#show lacp sysid
Channel group System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-30-F1-8F-2C-A7
2 32768 00-30-F1-8F-2C-A7
3 32768 00-30-F1-8F-2C-A7
4 32768 00-30-F1-8F-2C-A7
5 32768 00-30-F1-8F-2C-A7
6 32768 00-30-F1-8F-2C-A7
Console#
