Command Line Interface
4-110
4
show system vlan-auth
This command shows VLAN authentication related settings on the switch or a
specific interface.
Syntax
show system vlan-auth [interface interface]
• interface
• ethernet unit/port
- unit - This is device 1.
- port - Port number.
Command Mode
Privileged Exec
Example
Access Control List Commands
Access Control Lists (ACL) provide packet filtering for IP frames (based on address,
protocol, Layer 4 protocol port number or TCP control code) or any frames (based
on MAC address or Ethernet type). To filter packets, first create an access list, add
the required rules, specify a mask to modify the precedence in which the rules are
checked, and then bind the list to a specific port.
Access Control Lists
An ACL is a sequential list of permit or deny conditions that apply to IP addresses,
MAC addresses, or other more specific criteria. This switch tests ingress or egress
packets against the conditions in an ACL one by one. A packet will be accepted as
soon as it matches a permit rule, or dropped as soon as it matches a deny rule. If no
Console(config)#interface ethernet 1/5
Console#show system vlan-auth interface ethernet 1/5
VLAN Authorization (RFC 3580) is enabled on port 1/5
Administrative Egress: untagged
Operational Egress: none
VLAN ID: 0
Console(config-if)#exit
Console#show system vlan-auth
Global VLAN Authorization (RFC 3580) Parameters
VLAN Authorization: disabled
VLAN Authorization Port Summary
Port Status Administrative Egress Operational Egress VLAN ID
Eth 1/1 enabled untagged none 0
Eth 1/2 enabled untagged none 0
Eth 1/3 enabled untagged none 0
Eth 1/4 enabled untagged none 0
Eth 1/5 enabled untagged none 0
.
.
.
