Configuring the Switch
3-170
3
Web – Click Priority, ACL Marker. Select a port and an ACL rule. To specify a ToS
priority, mark the Precedence/DSCP check box, select Precedence or DSCP from
the scroll-down box, and enter a priority. To specify an 802.1p priority, mark the
802.1p Priority check box, and enter a priority. Then click Add.
Figure 3-105. Changing Priorities Based on ACL Rules
CLI – This example changes the DSCP priority for packets matching an IP ACL rule,
and the 802.1p priority for packets matching a MAC ACL rule.
Console(config)#interface ethernet 1/1 4-151
Console(config-if)#match access-list ip bill set dscp 0 4-124
Console(config-if)#match access-list mac mike set priority 0 4-134
Console(config-if)#end
Console#show marking 4-125
Interface ethernet 1/1
match access-list IP bill set DSCP 0
match access-list MAC a set priority 0
Console#
