4.18.2. OUT.N - Selecting the output
Acronym Scrolling message Submenu Attributes
OUT.N OUTPUT NUMBER OUTPU R W
The parameter shows and sets the identifying number of the output to be configured.
Unit of measurement: Number
Options: 1...4
4.18.3. STAT - Defining the output state
Acronym Scrolling message Submenu Attributes
StAt OUTPU.1 (o OUTPU.2… OUTPU.4) DIGITAL OUTPUT STATUS OUTPU R W
The parameter shows and sets the state of the output with identifying number “x”.
The active direct output corresponds to the relay, logic, or trial output ON (conducting).
The active inverse output corresponds to the relay, logic, or trial output OFF.
If the output is continuous, direct corresponds to minimum = 4mA and maximum = 20 mA, while inverse corresponds to
minimum = 20 mA and maximum = 4 mA.
The outputs can be forced so that they are always on or off.
On models 1650-1850, if the VT1, option is present, the parameter is ON.
Unit of measurement: -
Options: DIREC = Direct output
INVRS = Inverse output
OFF = Output forced off
ON = Output forced on
DI.PWM = Direct output with partialisation of ON/OFF and cycle time CY.TIM (for Output 1 of
CONT.A or CONT.C type only)
IN.PWM = Direct output with partialisation of ON/OFF and cycle time CY.TIM (for Output 1 of
CONT.A or CONT.C type only)
