gefran 850 User Manual

80209C_MHW_850-1650-1850_02-2020_ENG_pag. 180
if the Timer function is enabled:
TIM.RE = Remaining timer value
TIM.EL = Timer value elapsed
if controller model with valve control:
V.POSI = Valve position
if the Programmer function is enabled in parameter PROGR on the EN.FUN menu:
P.TIME = Current step time (ramp or hold)
P.T.TIM = Program total theoretical time
P.R.TIM = Program total theoretical residual time
IN1 = Main input
if model with auxiliar input 2
IN3 = Auxiliar input 2
if model with Modbus Master serial and Master parameter configured:
MAS.01 = Master value 1
MAS.02 = Master value 2
MAS.03 = Master value 3
MAS.04 = Master value 4
MAS.05 = Master value 5
MAS.06 = Master value 6
MAS.07 = Master value 7
MAS.08 = Master value 8
MAS.09 = Master value 9
MAS.10 = Master value 10
MAS.11 = Master value 11
MAS.12 = Master value 12
MAS.13 = Master value 13
MAS.14 = Master value 14
MAS.15 = Master value 15
MAS.16 = Master value 16
MAS.17 = Master value 17
MAS.18 = Master value 18
MAS.19 = Master value 19
MAS.20 = Master value 20
4.28.9. BAR.3 - Selecting bargraph 3 display
Acronym Scrolling message Submenu Attributes
bAr.3 HOME.1 (o HOME.2) BARGRAPH FUNCTION HOME R W
e parameter shows and sets the display assigned to the bargraph 3.
The parameter appears only if the controller is 1650 or 1850.
The parameter appears only if parameter bAr.E is at
- ON.ALL, NO.FRA and ON.3LY (on 1650)
- ON.ALL, ON.AL1, NO.FRA, NO.FR1, ON.3LY and ON.3L1 (on 1850)
Unit of measurement: -
Options: PV = Process variable
SETP = Local setpoint / manual power or active setpoint, in case of enabling Multiset function,
setpoint gradient, remote setpoint, and programmer (if enabled) (LED SP on)
SSP = Active setpoint ( LED SP on)
if the model with auxiliary input
IN2 = Auxiliary input
OUT.P = Power control output
SP-PV = Deviation |SP-PV|
HEAT = Heating power output with 0...100% control
COOL = Cooling power output with 0...100% control
HE+CO = Power control output -100...100% (positive for heating, negative for cooling)
if the model with CT1+CT2:
CURR1 = Current input CT1
CURR2 = Current input CT2
