gefran 850 User Manual

80209C_MHW_850-1650-1850_20-2020_ENG_pag. 27
OUT1 - Master Modbus output [with optional Output 1 (B) = G]
6
5
4
3
2
B (Data +)
A (Data -)
Master Modbus RS485
Output Out 2 - relay 5 A
19
20
21
22
23
24
NO
C
Relay 250 VAC, 5 A
Output Out 2 - logic
21
22
19
20
+
-
L
+V
Logic 24 V ±10%
(min 10 V a 20 mA9)
Output Out 2 - logic isolated
21
22
19
20
~ / =
L
Fuse
Logic 30 V AC/DC max
max 100 mA
Isolated 1500 V
Output Out 3 - logic
21
22
19
20
+
-
L
+V
Logic 24 V ±10%
(min 10 V a 20 mA)
Output Out 3 - logic isolated
21
22
19
20
~ / =
L
Fuse
Logic 30 V AC/DC max
max 100 mA
Isolated 1500 V
Output Out 3 - Triac
Triac 75...240 VAC
max 1 A
Isolated 3 kV
Output Out 2, Out 3, Out 4 - relay group 5 A
19
20
21
22
23
24
NO 4
NO 3
NO 2
C
Relay 250 VAC, 5 A
2.3.5. Digitali inputs
Digital inputs
16
15
14
13
COM
IN3
IN2
IN1
Digital inputs
voltage-free contact
Digital inputs
16
15
14
13
COM
IN3
IN2
IN1
NPN digital input
24 V, 4,5 mA
