80209C_MHW_850-1650-1850_02-2020_ENG_pag. 162
4.24.2. ENRG.N - Selecting energy counter
Acronym Scrolling message Submenu Attributes
ENRG.N ENERGY COUNTER NUMBER ENERG R W
The parameter shows and sets the identifying number of the energy counter to be configured.
Unit of measurement: Number
Options: 1...2
4.24.3. ENERG - Selecting the output for energy calculation
Acronym Scrolling message Submenu Attributes
ENERG ENERG.1 (o ENERG.2) ENERGY COUNTER ENABLE ENERG R W
The parameter shows and sets the output to be used for the energy calculation.
The controller totalizes the time during which the output is active and uses it for the energy calculation.
Unit of measurement: -
Options: OUt1 = Output 1
OUt2 = Output 2
OUt3 = Output 3
OUt4 = Output 4
4.24.4. V.LINE - Nominal line voltage
Acronym Scrolling message Submenu Attributes
V.LINE ENERG.1 (o ENERG.2) NOMINAL VOLTAGE ENERG R W
The parameter shows and sets the nominal line voltage to be used for the energy calculation.
Unit of measurement: V
Options: 0...999
4.24.5. P.LOAD - Nominal power of load
Acronym Scrolling message Submenu Attributes
P.LOAD ENERG.1 (o ENERG.2) LOAD NOMINAL POWER ENERG R W
The parameter shows and sets the nominal power of the load controlled by the output.
If the parameter is set to “0.00” the data used is the RMS current measured with the CT1 or CT1 + CT2 current transfor-
mer (optional).
Unit of measurement: kW
Options: 0.00...99.99
4.24.6. E.COST - Nominal cost per kWh
Acronym Scrolling message Submenu Attributes
E.COST ENERG.1 (o ENERG.2) ENERGY COST / KWH ENERG R W
The parameter shows and sets the nominal cost of energy per kWh.
Unit of measurement: Number
Options: 0.000...9.999
