80209C_MHW_850-1650-1850_02-2020_ENG_pag. 142
4.19.4. TYPE - Defining the type of analog output
Acronym Scrolling message Submenu Attributes
tYPE OUT.AN.1 (o OUT.AN.2) ANALOG OUTPUT TYPE OUT.AN R W
The parameter shows and sets the definition of analog output A1 or A2.
Unit of measurement: -
Options: 20MA = 0...20 mA Output
4-20M = 4...20 mA Output
10V = 0...10 V Output
2-10V = 2...10 V Output
C.20MA = 0...20 mA Custom output
C.4-20 = 4...20 mA Custom output
C.10V = 0...10 V Custom output
C.2-10 = 2...10 V Custom output
4.19.5. FUNC - Selecting the function assigned to the analog output
Acronym Scrolling message Submenu Attributes
FuNC OUT.AN.1 (o OUT.AN.2) REFERENCE SIGNAL ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the function assigned (retransmission of values) to analog output A1 or A2.
Unit of measurement: -
Options: NONE = No assigned function
HEAT1 = Heat control power of PID.1
COOL1 = Cool control power of PID.1
PV1 = Process variable 1
SSP1 = Active setpoint of PID.1
SETP1 = Local setpoint of PID.1
DEVI1 = Deviation |SSp-PV| of PID.1
SERIA = Value set from serial line
if the Programmer 1 function is enabled in parameter PROGR on the EN.FUN menu:
SLV.S1 = Slaved setpoint of PROGR.1
H+C1 = PID.1 heat/cool control output
if PID2.E function is enabled in EN.FUN:
HEAT2 = PID.2 heat control output
COOL2 = PID.2 cool control output
H+C2 = PID.2 heat/cool control output
PV2 = Process variable 2
SSP2 = PID.2 active setpoint
SETP2 = PID.2 local setpoint
DEVI2 = PID.2 deviation |SSp-PV|
if the Programmer 2 function is enabled in parameter PROGR on the EN.FUN menu:
SLV.S2 = Slaved setpoint of PROGR.2
IN1 = Main input
if the model with auxiliary input:
IN2 = Auxiliary input
if the model with auxiliary input 2:
IN3 = Auxiliary input 2
if model with Master Modbus serial (except output 1) and at least one Master parameter configured
as GF_eXpress:
MASTER = Master value (for type provided to word only) (index no. to be specified in MAST.N)
