gefran 850 User Manual

80209C_MHW_850-1650-1850_02-2020_ENG_pag. 175
4.28.1. HOME - Selecting Home
Acronym Scrolling message Submenu Attributes
HOME.N HOME NUMBER HOME R W
The parameter shows and sets the identifying number of Home to configure.
Unit of measurement: Number
Options: 1...2
4.28.2. BUT.1 - Selecting function key 1
Acronym Scrolling message Submenu Attributes
but.1 HOME.1 (o HOME.2) KEY FUNCTION HOME R W
The parameter shows and sets the function assigned to key 1 (
) of the controller.
Unit of measurement: -
Options: NONE = No function assigned
AU-MA = Automatic-Manual control
LO-RE = Local-remote setpoint mode
HOLD = Hold main input value
AL.ACK = Reset alarm latches
S.TUNE = Activate Self-Tuning
A.TUNE = Activate Auto-Tuning
OUT.S.R = Set/reset outputs set with BUT.SR function
INT.RS = Integral reset
if model is CT1+CT2:
CAL.HB = Alarm calibration HB
if the Multiset function is enabled:
SP.SEL = Select setpoint M.SP1.1/M.SP2.1
if enabled Options Logics:
LFB.IN = Input logic Function Blocks
In the case of a valve model with auxiliary input, linear custom type FUnC=VALV.P function,
and with one output set as V.OPEN and one output set as V.CLOS:
VALV.P = auxiliary input configuration
4.28.3. BUT.2 - Selecting function key 2
Acronym Scrolling message Submenu Attributes
but.2 HOME.1 (o HOME.2) KEY FUNCTION HOME R W
The parameter shows and sets the function assigned to key 2 (
) of the 1850 controller.
Unit of measurement: -
Options: As per but.1
4.28.4. BUT.3 - Selecting function key 3
Acronym Scrolling message Submenu Attributes
but.3 HOME.1 (o HOME.2) KEY FUNCTION HOME R W
The parameter shows and sets the function assigned to key 3 (
) of the 1850 controller.
Unit of measurement: -
Options: As per but.1
