gefran 850 User Manual

80209C_MHW_850-1650-1850_02-2020_ENG_pag. 183
4.29. Submenu LNR.4.P - Permits configuration of custom linearisation 4 points
Acronimo
Messaggio
a scorrimento
Password
d’accesso
Descrizione
LNR.4.P CUSTOM 4 POINT
LINEARIZATION
NUMBER
Level 2 Permits configuration of custom linearisation parameters to
4 points.
The submenu is visible only if custom linearisation has been
enabled in the configuration of the main input, the auxiliary
input or the third input.
4.29.1. LNR.4.N - Selection of custom linearisation
Acronym Scrolling message Submenu Attributes
LNR.4.N CUSTOM 4 POINT LINEARIZATION NUMBER LIN.4.P R W
The parameter shows and sets the identify Number of custom linearisation to configure.
Unit of measurement: Number
Options: 1...3
4.29.2. Md.4P - Four point linearisation method
Acronym Scrolling message Submenu Attributes
Md.4P (LIN.4.P.1 (0 LIN.4-P.2 o LIN.4-P.3) CUSTOM 4 POINT LINEARIZATION MODE LIN.4.P RW
The parameter allows you to set the insertion mode of the linearization points.
Unit of measurement: -
Options: RD.ADJ = manual point entry mode (redirects to paragraph 5.4. “Correction of four-point input” on page xxx)
CALIB = point entry method via calibrator reading (redirects to paragraph 5.4. “Correction of four-point
input” on page xxx)
Selection of
linearisation mode
186
Selection of custom
linearisation mode
186
X coordinate of first point 187
X coordinate of second point 187
Y coordinate of first point 187
Y coordinate of second point 187
Parameter Pag.
LNR.4.N
Md.4P
X1
Y1
X2
Y2
