4.30. Submenu LINRZ - Configuring custom linearization
Acronym Scrolling message Password Description
LINRZ CUSTOM
LINEARIZATION CONFIG
Level 2 Lets you configure the parameters for custom linearization in
32 steps or 4 points.
The submenu is visible only if custom linearization was
enabled in the configuration of the main input or of the auxi-
liary input.
LNRZ.N
STP.xx
MV.STA
MV.fUL
MV.50C
Selecting custom
linearization
185
VValue of step xx 185
Setting mV at start of
scale
186
Setting mV at
full scale
186
Setting mV at
temperature of 50°C
186
Parameter Pag.
4.30.1. LNRZ.N - Selecting custom linearization
Acronym Scrolling message Submenu Attributes
LNRZ.N CUSTOM LINEARIZATION NUMBER LINRZ R W
The parameter shows and sets the identifying number of the custom linearization to be configured.
Unit of measurement: Number
Options: 1...2
4.30.2. STP.xx - Value of step xx
Acronym Scrolling message Submenu Attributes
STP.xx LINRZ.1 (o LINRZ.2) CUSTOM LINEARIZATION STEP LINRZ R W
The parameter shows and sets the value of the various steps, with xx from 0 to 32.
The start scale value goes in STP.00 and the full-scale value in STP.32.
The value of the nth step corresponds to the input: mV start scale + n*ΔmV con ΔmV = (mV full scale - mV start scale)/32.
Unit of measurement: Scale points
Options: -1999...9999
