gefran 850 User Manual

80209C_MHW_850-1650-1850_20-2020_ENG_pag. 31
Output Out 2 – logic
+
-
19
20
8
7
+
-
L
+V
Logic 24 V ±10%
(min 10 V a 20 mA)
Output Out 2 - logic isolated
+
-
19
20
8
7
~ / =
L
Fuse
Logic 30 V AC/DC max
max 100 mA
Isolated 1500 V
Output Out 3 – relay 5 A
19
20
10
9
23
24
NO
C
Relay 250 VAC, 5 A
Output Out 3 – logic
+
-
19
20
10
9
+
-
L
+V
Logic 24 V ±10%
(min 10 V a 20 mA)
Output Out 3 - logic isolated
+
-
19
20
10
9
~ / =
L
Fuse
Logic 30 V AC/DC max
max 100 mA
Isolated 1500 V
Transmitter supply VT1
19
20
10
VT1
9
23
24
-
+
24 VDC ±10%, max 30 mA
Output Out 4 – relay 5 A
37
38
39
40
C
NO
Relay 250 VAC, 5 A
Output Out 4 –Triac
Triac 75...240 VAC
max 1 A
Isolated 3 KV
2.4.5. Digital inputs
Digital inputs
41
42
43
44
45
46
COM
IN1
IN2
IN3
IN4
IN5
Digital inputs
voltage-free contact
Digital inputs
41
42
43
44
45
46
COM
IN1
IN2
IN3
IN4
IN5
NPN Digital inputs
24 V, 4,5 mA
