4.9.3. TYPE - Selecting sensor type
Acronym Scrolling message Submenu Attributes
TYPE INPUT.1 (or INPUT.2) or INPUT.3 TYPE OF PROBE INPUT R W
The parameter shows and sets the sensor type of the main or auxiliary input.
The functions for calibrating Custom sensors are on the US.CAL menu.
When a 4...20 mA input is used and the current is less than 2 mA, an Err message is generated and the relay state speci-
fied with the FAUL.T parameters is activated.
The table shows the scale limits for each sensor type or input based on the set number of decimals.
Sensor type Sensor
Unit of
measurement
Scale limits for
DEC.P = 0
Scale limits for
DEC.P = 1
Error @ 25°C
Thermocouple
J °C -210…1200 -199.9...999.9 ±0,05
K °C -270…1372 -199.9...999.9 ±0,06
R °C -50…1768 -50.0...999.9 ±0,02
S °C -50…1768 -50.0...999.9 ±0,02
T °C -270…400 -199.9...400.0 ±0,04
C °C 0…2315 0.0...999.9 ±0,011
D °C 0…2315 0.0...999.9 ±0,023
B °C 40…1820 40.0…999.9 ±0,03
E °C -270…1000 -199.9...999.9
±0,19 per T<-200°C
±0,03 per T>-200°C
L °C -200…900 -199.9...900.0 ±0,09
L-GOST °C -200…800 -199.9...800.0 ±0,014
U °C -200…600 -199.9...600.0 ±0,135
G °C 0…2315 0.0…999.9 ±0,042
N °C -270…1300 -199.9...999.9 ±0,047
Pt20Rh Pt40Rh °C 0…1888 0…999.9 ±0,017
Infrared
characteristic of the Tc K
model see note
1 °C 10...700 10.0...70.0 ±0,06
2 °C 60...120 60.0...120.0 ±0,06
3 °C 115...165 115.0...165.0 ±0,06
4 °C 140...260 140.0...260.0 ±0,06
Thermoresistance
PT100 °C -200...850 -199.9...850.0 ±0,062
PT100 LIM °C -50...250 -50.0...250.0 ±0,062
JPT100 °C -200...600 -199.9...850.0 ±0,062
Voltage /Current
0...60 mV
-1999...9999 -199.9...999.9 -
0...20 mA
4...20 mA
0...10 V
2...10 V
0...5 V
1...5 V
0...1 V
0...2,4V HI
0...1,2V HI
0...1V HI
Custom
RTD
-1999...9999 -199.9...999.9 -
0...60 mV
0...20 mA
4...20 mA
0...10 V
2...10 V
0...5 V
1...5 V
0...1 V
0...2,4V HI
0...1,2V HI
0...1V HI
Note: the infrared temperature sensor has an output in voltage for direct connection to the input terminals of the temperature controller. An
external thermometer is needed in order to correct the sensor error.
After identifying the work temperature range (for example, 140 – 260°C), set an SP near the minimum scale value, and after reaching it make
a note of value A1 indicated by the instrument and of value A2 indicated by the external thermometer. Set an SP near the maximum scale
value, and after reaching it make a note of value B1 indicated by the instrument and of value B2 indicated by the external thermometer.
Enable 4-point linearization (see Correcting 4-point input) and enter the four requested values (A1, B1 and A2, B2).
