80209C_MHW_850-1650-1850_02-2020_ENG_pag.
55
4.2.1.
Functional schema
Scrolling messages
1...3 languages with
1...25 posts
or
1...75 posts
User menu 1...100
param.
Recipes 1...5
1...25 param.
Digital inputs
function
Alarm HB
Outputs
function
Alarm 1...4
V
alve control
Weekly
Calendar
Linearization
LINRZ.1
Linearization
LINRZ.2
Setpoint
programmer
PROGR.1
Programmatore
di setpoint
PROGR.2
PID control
PID.1
PID control
PID.2
Alarm
F
AUL
T
.1
Alarm
F
AUL
T
.2
Other functions
Double functions
Analog input
IN.1
Analog input
IN.2
Analog input
IN.3
Current input
CT
.1
Current input
CT
.2
Digital input
INDIG.1
Output
OUT
.1
Digital input
INDIG.2
Output
OUT
.2
Digital input
INDIG.3
Output
OUT
.3
Analog output
OUT
.A2
Digital input
INDIG.4
Output
OUT
.4
8 Digital outputs
EXP
8 Digital inputs
EXP
Digital input
INDIG.5
Analog output
OUT
.A1
8 Relay outputs
EXP
Master Modbus serial
local / remote
Setpoint
SET1
local / remote
Setpoint
SET2
PROCESSING SOFTWARE
OUTPUTS
INPUTS
Multiset
M.SP1.1...
...M.SP4.1
Multiset
M.SP1.2...
...M.SP4.2
Logic
functions
1...32
Mathematical
functions
1...8
Master Modbus
1….20
communication
functions
Timer
TIMER.1
Timer
TIMER.2
Alarm
POWER.1
Alarm
POWER.2
Alarm
LBA.1
Alarm
LBA.2
PID
parameters
PIDGR.1
PID
parameters
PIDGR.2
Counter
energy
ENERG.1
Counter
energy
ENERG.2
16 Programs
192 Steps
Controller
in cascade
Ratio controller
Funzioni con definizione da GF_eXpress
56
58
