4.23.2. TIME.N - Selecting timer
Acronym Scrolling message Submenu Attributes
TIME.N TIMER NUMBER TIMER R W
The parameter shows and sets the identifying number of the timer to be configured.
Unit of measurement: Number
Options: 1...2
4.23.3. FUNC - Selecting Timer function mode
Acronym Scrolling message Submenu Attributes
FunC TIMER.1 (o TIMER.2) TIMER FUNCTION TIMER R W
The parameter shows and sets the timer function mode.
The Timer function is explained in detail in paragraph “5.11. Timer” on page <?>.
Unit of measurement: -
Options: ST.STP = Start/Stop Timer
STABL = Stabilization Timer
SWITC = Power-on Timer
4.23.4. ST.ST - Selecting the Start/Stop timer command
Acronym Scrolling message Submenu Attributes
St.St TIMER.1 (o TIMER.2) TIMER START STOP TIMER R W
The parameter shows and sets the “object” that commands timer Start/Stop and stabilization.
Unit of measurement: -
Options: IN.DIG = From digital input
ALRM1 = From alarm 1
ALRM2 = From alarm 2
ALRM3 = From alarm 3
ALRM4 = From alarm 4
AL.HB = From alarm HB
SERIA = From serial
4.23.5. S.S.T - Defining the Start/Stop timer command logic
Acronym Scrolling message Submenu Attributes
S.S.t TIMER.1 (o TIMER.2) LOGIC TYPE OF TIMER START/STOP TIMER R W
The parameter shows and sets the type of logic used to command timer Start/Stop.
With positive logic, timer start corresponds to “object” active if IN.DIG input active.
With negative logic, timer start corresponds to “object” inactive if IN.DIG input inactive.
Unit of measurement: -
Options: POSIT = Positive logic
NEGAT = Negative logic
