if model with Modbus Master serial and Master parameter configured:
MAS.01 = Master value 1
MAS.02 = Master value 2
MAS.03 = Master value 3
MAS.04 = Master value 4
MAS.05 = Master value 5
MAS.06 = Master value 6
MAS.07 = Master value 7
MAS.08 = Master value 8
MAS.09 = Master value 9
MAS.10 = Master value 10
MAS.11 = Master value 11
MAS.12 = Master value 12
MAS.13 = Master value 13
MAS.14 = Master value 14
MAS.15 = Master value 15
MAS.16 = Master value 16
MAS.17 = Master value 17
MAS.18 = Master value 18
MAS.19 = Master value 19
MAS.20 = Master value 20
4.28.7. BAR.1 - Selecting bargraph 1 display
Acronym Scrolling message Submenu Attributes
bAr.1 HOME.1 (o HOME.2) BARGRAPH FUNCTION HOME R W
The parameter shows and sets the display assigned to the bargraph 2.
The parameter appears only if the controller is 1650 or 1850.
The parameter appears only if parameter bAr.E is at
- ON.ALL and NO.FRA (on 1650)
- ON.ALL, ON.AL1, NO.FRA and NO.FR1(on 1850)
Unit of measurement: -
Options: PV = Process variable (the PV LED will light up only if this item is selected)
SETP = Local setpoint / manual power or active setpoint (read only), in case of enabling Multiset
function, setpoint gradient, remote setpoint, and programmer (if enabled).
SSP = Active setpoint (read only)
if the model with auxiliary input
IN2 = Auxiliary input
OUT.P = Power control output (on 1850 LED % on)
SP-PV = Deviation |SP-PV|
HEAT = Heating power output with 0...100% control (on 1850 LED % on)
COOL = Cooling power output with 0...100% control (on 1850 LED % on)
HE+CO = Power control output -100...100% (positive for heating, negative for cooling)
(on 1850 LED % on)
if the model with CT1+CT2:
CURR1 = Current input CT1 (on 1850 LED A on)
CURR2 = Current input CT2 (on 1850 LED A on)
if ENERG function enabled and model with CT1+CT2:
CURR = Load current (on 1850 LED A on)
if the ENERG function is enabled:
OUT.KW = Power on load
if the Timer function is enabled:
TIM.RE = Remaining timer value
TIM.EL = Timer value elapsed
if controller model with valve control:
V.POSI = Valve position
if the Programmer function is enabled in parameter PROGR on the EN.FUN menu:
P.TIME = Current step time (ramp or hold)
P.T.TIM = Program total theoretical time (only for model 850)
